XY-AI-398A Semi automatic multi rolls toilet paper packing machine
1. Multi function: automatic conveying, single head operation, automatic feeding, automatic sealing, automatic countering.
2. Adopting the advanced PLC computer programming control and employing the liquid crystal text to display parameters, it is with simple set and water cooling control. Moreover, its temperature controlling is more precise so that heating wires and tapes with thermo stability can be protected more efficient. The machine use the servo motor to push the products to the bags, it causes to locating the products more accurately.
3. Packing and sealing are pretty and tidy. The machine can be operated with full-automation and semi-automation. The machine with conveyer can be connected with automatic toilet roll packing machine with conveyer. This allows the machine have high capacity and therefore to save the labor and reduce production cost.
4. Capacity: 8-12 bundling bag/min, 1 labor only to pack.
5. Suitable for core or coreless toilet roll. The machine cannot proofread color code automatically.
6. Comprehensive design, rigid frame, and imported major component, this allows our machine work steadily& efficiently, and therefore this makes our machine have long life.
| Model | XY-AI-398A |
| Air supply | 0.6Mpa |
| Power supply | 4Kw 220V 50HZ |
| Speed | 8-12 bundling bag/min |
| Single roll size | Diameter:Ø90-120mm Height:90-140mm |
| Bundling Size | L(360-650)*W(180-240)*H(90-140)mm |
| Machine size | L5000*W1000*H1500mm |
Production line:
XY-TQ-A-G Fully Automatic Toilet Paper Production Line
| SAY USD DOLLAR ONLY. (FOB Xiamen Price USD) | |
| Packing: In standard export packing wooden pallet. Terms of payment: 100% TT(Pay 30% deposit in advance ,the 70% balance is paid before shipping). Delivery time: About 90days. Guarantee: One year from date of Bill of Lading. Bank Details: BENEFICIAY:Fujian Xinyun Construction Development Co., Ltd OUR BANK AND ACCOUNT: BANK: China Construction Bank Fujian Branch ADDRESS: NO.142 Guping Road Fuzhou Fujian China SWIFT CODE: PCBCCNBJFJX ACCOUNT: 35050165690709201872 | | |
